FILE

191

Power meter

Power meter data

3. Press Destination[F3] to select the destination for

the file type:

For State data:

Local state data

For Trace data:

Trace1~4

For Limit Lines:

Limit line 1~5

For Correction:

Correction data 1~5

For Sequence:

Sequence 1~5

For Power Meter:

Power meter 1 ~5

Recall File

1. Press Recall From[F1] and select a source

location:

Internal memory registers,
these internal registers are not
part of local memory

Local:

Internal memory

USB

External USB memory

SD Card:

External micro SD card

2. To Recall the selected file type, press Recall

Now[F1].

3. A message “Finish‼” will be displayed at the

bottom of the screen when the recall is
successful.

Note

The USB and micro SD card options will only be
available when a flash drive/SD card is inserted
into the front panel ports.
