ADVANCED OPERATION

163

to edit (must start at #1).

4. Press Limit Offset[F3] and set offset level for the

point.

5. Press Mkr Data to Point[F2].This adds the

currently active marker’s position to the
selected point.

6. The marker position can be moved at this point

using the scroll wheel. Press the Enter key to set
the position.

7. Repeat steps 3-5 for any other points (max 10).

8. Press Return[F7]>Save Limit Line[F5] to save the

currently selected limit line.

Note

Using this function will also change the position of
marker 1 outside of the limit function.

Delete Limit Line

Description

Any one of the 5 limit lines can be deleted.

Activate
Correction

1. Press

Limit

Line

> Edit Limt Lines[F1]>Limit Line[F1]

and choose a limit line (limit line 1~5) to delete.

2. Press Delete Limit Line[F6]. The data from the

chosen limit line will be deleted.

Pass Fail Testing

Description

Before pass/fail testing can begin, limit lines for
the upper and lower limits must first be saved.
See the page 116.
