GSP-930 User Manual
196
4. Press
System
>More 1/2[F7]>RmtInterface
Config[F2]>GPIB Addr and set the GPIB
address.
GPIB address 0~30
GPIB constraints  Maximum 15 devices altogether, 20m cable length,
2m between each device
 Unique address assigned to each device
 At least 2/3 of the devices turned On
 No loop or parallel connection
Configure the LAN and LXI Interface
The GSP-930 is a class C LXI compliant instrument. The LXI
specification allows instrumentation to be configured for basic
remote control or monitoring over a LAN.
For details on the LXI specification and compliance classes, please
see the LXI website @ http://www.lxistandard.org.
Background The LAN interface is used for remote control
over a network. The spectrum analyzer
supports DHCP connections so the instrument
can be automatically connected to an existing
network. Alternatively, network settings can
also be manually configured.
LAN
configuration
Settings IP Address Default Gateway
Subnet Mask DNS Server
DHCP on/off
Connection Connect an Ethernet cable from
the network to the rear panel LAN
port.
