GSP-930 User Manual
148
2. Press Ref. Channel[F2] and set the following:
RBW[F3] Sets the resolution
bandwidth.
3. All other reference channel settings are pre-
defined.
4. Press Return[F7] to return the previous menu.
5. Press Offset/Limit[F3]>Duplexing Mode[F1] and
choose FDD or TDD duplexing:
6. For FDD, press FDD Setup[F2] set the FDD
parameters, for TDD, press TDD Setup[F3]:
Transmission[F1] Toggles between BS and
UE testing
Chip Rate[F2] Selects the bandwidth of
the RRC filter that is
used to measure the in-
channel power for TDD
duplexing:
3.84MHz, 1.28MHz,
7.68MHz
Max Out Pwr[F2/F3] Sets the maximum
output power for BS
tests:
P>=43
39<=P<=43
31<=P<=39
P<31
