FILE
187
Save Files
Description Any function settings or configurations that
have been applied to the spectrum analyzer can
be saved using the
Save key.
Connect External
Memory To save files on a USB flash drive or micro SD
card, insert the appropriate device into the front
panel ports.
Save File 1. Press
Save to enter the Save menu.
2. Press Type[F2] and select a file type to save. See
page 179 for details on file types:
State: State data
Trace: Trace data
Screen: Screen shots
Limit Line: Limit line data
Correction: Correction data
Sequence: Sequence files
Power meter Power meter data
3. Press Data Source[F3] to select a data source for
the file type if needed:
For state data: Local state data
For trace data: Trace1~4
For screen shots: Normal: Screen shot is saved
as is
Save Toner: inverts the image
file color to reduce ink when
printing.
For limit line: Limit line 1~5
For correction: Correction data 1~5
For sequence: Sequence 1~5
