ADVANCED OPERATION

123

FM Analysis

Description

When frequency modulation is turned on, the
input signal is centered on the carrier frequency
and the span is automatically set to zero-span.

Measurement
items

Freq. Deviation:

Current, Min, Max

Mod. Rate:

Current, Min, Max

Carrier Pwr:

Current, Min, Max

Carrier Freq Offset:

Current, Min, Max

SINAD:

Current, Min, Max

Operation:
configuration

1. Set the center frequency to the carrier frequency

(page 39).

2. Press

Meas

> Demod[F2]>FM Analysis[F2]>FM

Analysis[F1] and turn FM analysis on.

Any other measurement mode will automatically be
disabled.

3. The display splits into two screens. The top

shows the FM waveform in the time domain.
The bottom screen shows the FM measurement.
