DAR
WIN Hardware Configurator
Report Printing ON/OFF
Set whether the report should appear on print (ON) or not (OFF).
Report Starting Time
Set the Starting Time in the format day of month : time. Define the day of month field
within a 01-28 range and the time field within a 00-23 range.
Report Channels
There are sixty report channels, from R01 to R60. Assign channels for measuring objects
being computed or Math channels and the type of Math on a report-channel basis. When
making a Math report, let computing start before making the report start.
Types of Computing
Select one of the below:
Type Data Item for Computing (Math)
INST Instantaneous value at the time of making report
AVE Average, maximum and minimum over the computing period
SUM Sum and cumulative sum over the computing period
Sum: The total sum over an hour for hourly reports, the sum over a day for
daily reports or the sum over a month for monthly reports. The
instrument resets this value each time it makes any of these reports.
Cumulative sum: The total sum up to the preset time to make a report in the case of
hourly reports or the sum up to a preset time of the day to make a
report in the case of daily reports. The instrument resets this value at
each preset time or at each preset time of the day for report making.
The instrument does not perform cumulative summation for monthly
reports.
Unit of Summation (Sum Unit)
Input data items like flow rates, that have a unit in /sec, /min, /hour or /day, give Math
results that differ from their actual values when simply summed. This occurs because the
unit of such a data item differs from that of the measurement interval.
In such cases, take the output after having converted the Sum Unit so it matches that of
the input data item applied.
Unit of Input (Preset Unit) Conversion Formula
INTVL (no conversion)
∑ (measured data values)
/sec ∑ (measured data values) × measurement interval
/min ∑ (measured data values) × measurement interval/60
/hour ∑ (measured data values) × measurement interval/3600
/day ∑ (measured data values) × measurement interval/86400
Copying settings
Channel No., Type, and Sum Unit settings can be copied to other channels as explained
in Section 4.11, “Copying Channel Settings.”
Sorting the channel order
It is possible to automatically sort report channels following each other up from a report
base channel.
For example, if Report channel R03 is object for channel 005, report channels R04 and
up, will automatically become object for channels 006, 007, 008, ...etc.
To sort the channels, click the report channel from which up you want channels to be
sorted and drag it down. Click sort to start sorting.
4.23 Report Settings
