T
ag Editor
7.3
Setting Tag Nos. and Tag Comments
1
On the Tag Editor screen, clicking the area showing the name of the Tag No. or
Tag Comment displays an edit box.
2
Enter the Tag No. or Tag Comment in the edit box.
Tag Nos. can be up to 8 characters and Tag Comments can be up to 16. If you
are going to write to the DC100 or DR, use only the following characters. All other
characters (including double-byte characters) will be replaced with some other
appropriate characters such as spaces.
0 to 9 A to Z : # % & ( ) * + - . /
Copying and pasting Tag Nos. and Tag Comments
Copies the Tag No. and Tag Comment of one channel to another channel.
1
On the Tag Editor screen, click the number at the No. column to select the copy
source.
2
Click the copy button on the toolbar or select Copy from the Edit menu.
Paste button
Copy button
3
Click or drag the number(s) at the No. column to select the copy destination.
4
Click the paste button on the toolbar or select Paste from the Edit menu.
Sorting
The list can be sorted in alphabetical order by channel numbers, Tag Nos., Tag
Comments, and mode/range.
1
Click the Channel, Tag No., Tag Comment, or Mode/Range on the Tag Editor
screen, or point to Sort by from the View menu and select the sorting type,
Channel numbers, Tag Nos., Tag Comments, or Mode/Range.
Note
Selecting the same sorting type consecutively switches the ascending/descending order.
