4-30 IM WX102-01E
Selecting Actions
Actions may be selectable depending on earlier Events and Edge/Level action settings.
The following describes all available actions:
ALARM ACK
This allows alarm acknowledgment.
ALARM RST
Resets alarms. When the “RELAY” is selected for an event, this function cannot be
selected.
TIMER RST
Resets timers.
RECORD (DR only)
• ON: Starts recording. The recording format is set individually.
• OFF: Stops recording. The level action does not include record ON/OFF functions.
• When the level action is set, the ON/OFF functions using the RECORD key are
disabled.
• The edge and level actions cannot be set simultaneously.
• For the level action, only one action is available.
MANUAL PR (DR only)
Enables manual printing.
DIGITAL PR (DR only)
• Digital printing starts in the analog trend mode. The recording intervals depend
on the timer setting (see Section 4.15). When the event/action functions are set,
normal digital print functions are disabled.
• Only one setting can be made in the event/action function.
MSG PR (DC100, and DR only)
• Prints messages.
• Select any message from the corresponding codes 01 to 20.
MSG DISP (DC100, and DR only)
• Displays messages.
• Select any message from the corresponding codes 01 to 20.
• To cancel the message display, press any key.
SPEED CHG (DR only)
• Changes chart speed 1 to chart speed 2. When the recording interval is set to
automatic (see Section 4.16), the recording interval is also changed. When the
event is released, the chart speed and recording interval return to their original
positions.
• Only one setting can be made in the event/action function.
GR TREND (DR only)
• This executes the recording in a channel in which the group setting has already
been made. For this, set the dot-recording to “GROUP” and start recording by key
operations following the “RECORD” given above.
• Select any group from G01 to G07.
• Only one identical group can be set in the event/action functions.
Note
• If Chart End appears, counter-actions such as RECORD ON are not executed.
• Actions such as RECORD or SPEED CHG may operate later than an event occurrence. For
example, with RECORD set in the action setting, if an alarm occurs, the measured values in
that condition are not recorded. This is because recording operations are delayed due to an
action operation.
4.14 Event/Action, Match Time, and Group Settings
