Note
• To easily put cursor’s at the first and last measurement data, select Edit > Select All, from
the menubar.
• Cursors will appear both on the waveform and on the digital value sheet.
• If a different display group is selected, cursors will appear in the same position on that
display.
• When you move a cursor in the waveform display using your mouse while the Cursor Value
window is still open, values in the Cursor Display window will also change.
• To move only cursor A in the display screen, press the Control button, and click on the
position where you want the A cursor to appear. To move only cursor B in the display screen,
press the Shift button, and click on the position where you want the B cursor to appear.
6.6 Cursor Measurement
