Remote Monitor Software
Saving connection conditions
5 Select from the Remote Monitor menubar File > Save As… . Enter a file name,
select the desired directory and click the Save button.
Note
Waveform display settings will also be saved when you save the connection conditions.
Connecting with earlier set connection conditions.
Connect the host PC in one of the following two ways to open earlier set connection
conditions:
• Click File and select a file from the pull-down menu (if no conditions have been saved
earlier, only the word “Latest File” will appear).
• Click File > Open, and select a file from the dialog box.
9.2 Connecting the Host and Saving Connection Conditions
