Remote Monitor Software
Procedure for Circular Monitor
The DAQ can display 1800 measurement data points. The waveform may not go around
the entire screen depending on the recording period set by the logger function of the
host, and the display time of the circular monitor.
Setting the Tome Axis
1. Choose a time of 1 hr., 2 hrs., 6 hrs., 12 hrs., 16 hrs., 1 day, 2 days, 1 week, 2 weeks,
or 4 weeks from the [Time Axis].
Alarm Display Placement
You can set the alarm display inside or outside of the waveform.
1. Change the settings from [View] to [Alarm Inside] or [Alarm Outside]. The other
operations are the same as ones like the trend display.
9.1 Operating the Remote Monitor
