Communication Software
2.1 Launcher Software
Launcher Software enables you to launch each DAQ 32 Plus software, use the Project
Function, and to protect software settings.
Launching each DAQ 32 Plus software
Select from the Start menu, Programs > YOKOGAWA DAQWORX > DAQ 32 Plus >
Launcher.
Software start buttons (see below) will be displayed automatically when Launcher
software is opened. The seven kinds of software are Software Configurator, DARWIN
Hardware Configurator, Logger, Historical Viewer, Tag Editor, Remote Monitor, and File
Utility.
Tag Editor start button
DARWIN Hardware Configurator start button
Software Configurator start button
Historical Viewer start button
Logger start button
Menu button
Launcher button Task bar
Remote Monitor start button
File Utility start button
right click left double-click
Project function
A Project is a saved group of DAQ 32 Plus software settings with changed conditions.
Using the Project Function it is possible to open software which settings were changed
earlier. In order to do this you must have saved the setting conditions you created earlier
as a Project. The Project Function is useful if you want to observe DA100/DC100/DR
measurement data on only one PC with a number of people. It enables one user to
observe waveforms without influencing other people’s settings. Note that you can only
open a Project after you have closed other DAQ 32 Plus software.
Protection settings
Enables you to protect settings from getting erased. After a password is entered (in the
Project Settings dialogbox), the toolbar will become pink to mark that protection is active.
Software version
To check software name, version, and license information click About... on the menu.
