Historical V
iewer Software
Note
• You can not set more than one User Defined mark at once.
• In the waveform display area User Defined marks are colored green, Trigger Marks are
yellow. On the digital value Sheet, User Defined mark are indicated by a green flag, Trigger
Marks by a yellow flag.
Deleting Marks
To delete marks from the waveform display area:
1 First capture them between cursor A and B.
2 Then select Edit > Delete Mark.
Both Trigger marks and User Defined marks in the captured range will be deleted.
Resetting Marks
If you wish to reset User Defined marks select Edit > Reset Mark.
All User Defined marks will be deleted. If you deleted the trigger mark it will be reset.
6.12 User Defined and Trigger Marks
