Before Operation
1.4 Opening and Closing each Software
Opening DAQ 32 Plus Software
1 Select from the Start Menu, Program > YOKOGAWA DAQWORX > DAQ 32 Plus
> Launcher.
When the Launcher software is activated, the below Launcher buttons will appear
in the top of your screen. From the left to the right use the Menu button, Logger
button, Historical Viewer button, File Utility button, Remote Monitor button,
DARWIN hardware configuration button, Software configuration button, and Tag
Editor button.
Tag Editor start button
DARWIN Hardware Configurator start button
Software Configurator start button
Historical Viewer start button
Logger start button
Menu button
Launcher button Task bar
Remote Monitor start button
File Utility start button
2 Open the desired software by clicking its Launcher button. You can also select the
software after right-clicking the DAQ 32 plus icon on the taskbar (see below).
Note
• To simultaneously open several Historical Viewer screens, open Historical Viewer by
selecting from the Start Menu, Program > YOKOGAWA DAQWORX > DAQ 32 Plus >
Historical Viewer.
When Historical Viewer is opened like this, data which are actively being recorded with
Logger software cannot be viewed.
• Software which can be activated simultaneously are Logger software, Historical Viewer,
File Utility software, Remote Monitor software, and DARWIN hardware configuration
software. Tag Editor software can be simultaneously used with Historical Viewer/ File Utility
software/ Remote Monitor software. Remote Monitor software, and Software configuration
software, can also be used simultaneously. Other software combinations can’t be activated
simultaneously.
First exit the non-matching software to activate the launcher icons for other software.
• When using a DC100 or DR for the first time, make sure to configure the devices with the
actual device. After this initial configuration you can use DAQ 32 Plus software, to make
configurations.
