DAR
WIN Hardware Configurator
Digital Printout Setting (DIGITAL PR)
This setting can be selected for each channel from the following. This setting applies to
the digital print of the analog mode and logging mode.
The recording interval can be selected from the following.
If the instrument is equipped with the optional computation function or floppydisk drive,
this setting can also be made for computation channels A01 to A60.
When LOG INTERVAL is set to SINGLE: The recording interval is decided automatically,
depending on the chart speed, and the columns of channels to be printed.
When LOG INTERVAL is set to MULTIPLE: The recording interval can be selected from
six timer settings. The default value is 1.
Trend Recording
Recording can be set ON/OFF per channel. The default setting is ON.
Manual Printout Setting (MANUAL PR)
This setting can be selected from the following. The default setting is ON.
If the instrument is equipped with the optional computation function or floppydisk drive,
this setting can also be made for computation channels A01 to A60.
OFF: Manual printout will not be carried out for this channel;
ON: Manual printout will be carried out for this channel.
Scale Printout (SCALE PR)
Assigned to each channel individually. The scaled values will be printed out with
trend recordings. No printout if a zone of 49mm or less is set. The scaled values of
the following channels will be printed. If the instrument is equipped with the optional
computation function or floppydisk drive, this setting can also be made for computation
channels A01 to A60.
When Partial Expanded Recording is OFF
OFF : Scaled values will not be printed.
ON1 : • when the recording zone is 150mm or more: scaled values at each 20%-interval
of the recording span will be printed at positions at 20%-intervals of the zone.
• when the recording zone is 50mm to 149mm: scaled values at 0% and 100% of
the recording span will be printed at 0% and 100% positions of the zone.
ON2 : Scaled values at 0% and 100% of the recording span will be printed at 0% and
100% positions of the zone.
ON3 : • when the recording zone is 100mm or more: scaled values at 0%, 50% and
100% of the recording span will be printed at 0%, 50% and 100% positions of
the zone.
• when the recording zone is 50mm to 99mm: scaled values at 0% and 100% of
the recording span will be printed at 0% and 100% positions of the zone.
When Partial Expanded Recording is ON
OFF : Scaled values will not be printed.
ON1/ON2/ON3 : When the recording zone is 100mm or more: scaled values at 0%,
100% of the recording span and at the boundary value will be printed
at 0%, 100% and boundary value positions of the zone. When the
recording zone is 50mm to 99mm: scaled values at 0% and 100% of the
recording span will be printed at 0% and 100% positions of the zone.
List Printout (LIST PR)
This setting can be assigned to each channel individually. Starting a list printout can be
done at the PRINT menu. For instruments with the optional Math function or floppydisk
drive, this setting can also be made for computation channels A01 to A60.
OFF: List printout will not be printed.
ON: Setting information per channel will be printed.
4.6 Recording-related Settings (DR Only)
