4.8
Tag Settings (DC100 or DR Only)
1
To open the Channel Settings related setting screen, click the Channels tab, or
select Settings > SET (Regular) Settings > Channel Settings from the menubar.
For the Math channel related setting screen click the Math tab, or select Settings
> SET (Regular) Settings > Math Functions from the menubar.
Tag setting
2
Set a tag in the setting area below the Tag label. Maximum amount of
alphanumerics for DC100: 8; for DR: 16. Additionally allowed symbols #, %, &, ( ),
*, +, -, ., and /.
