Logger Software
Miscellaneous settings
6 To collect, besides Measurement data, Math, Alarm or Report data check the
Math data, Alarm data, or Report data checkboxes in the Miscellaneous dialog
box.
7 If you selected Math data above, use the dialog box on the right to set the Math
action to either Clear, Start, Stop, or Clear & Start.
Note
• For DA100, DC100, and DR with/M3 option report data can be collected if Report data is
checked.
• Report data will be collected if a report file is created for DA100, DC100, or DR. Report
names will be, for hourly reports (Hourly-YYYYMMDDHH.RBI), for daily report (Daily-
YYYYMMDDHH.RBI), and for monthly reports (Monthly-YYYYMMDDHH.RBI). YYYY (year),
MM Month, DD (day), and HH (hour), mark the time when the report was created.
• The report file is saved in the same directory as the measurement data file.
• If the time on your DARWIN instrument changes from summer to wintertime (resulting in one
hour which is measured twice) a second daily report will not be created.
Saving Channel settings
8 To select the kind of recording channels you want to save, click either All or
Specified Channels in the Recording Channel dialog box. If you want to save
Specified Channels, click the Select button on the right, in the Channel setting
screen that opens, select the channels you want to save, and click OK.
File and saving condition settings
9 In the File Settings dialog box enter a File name. If you check Append Date the
complete file name will be: File Name - Date - Follow-up number .DAQ (.DAQ
being the extension). For example; AAA-19981228-0001.DAQ.
10 If you want to limit the length of files, check the Set File Length box, and the File
Length. Only the entered data amount will get saved.
11 If you wish to overwrite files starting with those saved last, check Auto file delete...
, and enter which files should be kept.
5.2 Logging Configuration
