7-2 IM WX102-01E
7.2 Receiving Tag Data
Reads in the tag data that are set by the DR or DC100.
Select whether to receive the tag data as Tag Nos. or Tag Comments.
1 Click the Receive Tag No. button or the Receive Tag Comment button on the
toolbar or select File > Receive from the menu and select Receive Tag No. or
Receive Tag Comment.
Receive Tag Comment button
Receive Tag No. button
Tag data are received as Tag Nos. if you select Receive Tag No.
Tag data are received as Tag Comments if you select Receive Tag Comment.
Note
• The tags from the DC100 are eight alphanumeric characters or less in length.
• The tags from the DR are 16 alphanumeric characters or less in length. If the data are
received as tag No., the first eight characters are read in.
• The Tag No., Tag Comment, and Mode/Range columns for the channels that do not have
tag data will show blanks.
• °, Ω, and Ω are replaced with spaces. µ and ε are replaced with ‘u’ and ‘e,’ respectively.
• [deg] was unchanged.
