No. Message/Corrective action
E0212 Can’t read file.
Check the existence of the file. Check that the file system is operating properly.
E0213 Can’t open file.
Check the existence of the file. Check that the file system is operating properly.
E0214 Insufficient disk capacity.
Free disk space.
E0215 No such file.
Check the existence of the file.
E0216 Illegal file name.
Use a different file name.
E0401 Communication error.
The Logger Software cannot communicate while the setup software is communicating.
Check that the DARWIN is turned ON, the communication module is being recognized by the DARWIN (DR/
DC), and the cable is connected properly.
In addition, check the following items according to the communication methods.
For GP-IB communication:
Is the address correct? Is the driver is properly installed? Is the GPIB card manufactured by NI?
For Ethernet communication:
Is the address correct? Is the TCP/IP protocol installed in Windows?
For RS-232-C, RS-422-A, and RS-485
Is the baud rate correct? Is the port (COM1 to COM4) correct? Is the address correct (RS422)? Is the PC’s
serial port functioning? Is the correct type of cable being used?
E0404 Can’t load DLL of GPIB.
Correctly install the GPIB driver.
Error Messages
No. Message/Corrective action
E3401 Incorrect Password.
Enter the correct password.
E3402 Passwords may not be blank.
Enter the password.
E3403 Project names may not be blank
Enter the project name.
Error Messages
No. Message/Corrective action
E3001 Incorrect File type or Version!
The program will use default settings because the previous settings (such as display settings) could not be
loaded.
11.2 Error Messages and Corrective Actions
