DAR
WIN Hardware Configurator
Selecting Events
Select any event from among the following:
NONE — releases the event/action setting.
REMOTE
• This menu is displayed only with the DI/DO modules that are recognized as system
modules.
• When a remote control signal is applied, the action is executed.
• There are 12 control signals available. Select any control signal from these
numbers for event setting. Remote control signal terminal numbers are applicable
for this selection.
ALARM
If an alarm occurs, the action is executed.
RELAY
If the selected internal switch or relay is operating, the action is executed. When the
alarm module or the DI/DO modules are not recognized as system modules, the relay
is set to OFF.
CHART END
When the end of the chart is detected, the action is executed.
FILE END
When the end of file (the time when the writing operation is terminated and the file is
closed) is detected, the action is executed.
TIMER
• If the selected timer’s set time is up, the action is executed. Six timers are
available. Select any from among these timers. See Section 4.15, “Setting Timers
and Summer/Winter Time.”
• In combination with the level action, the action is repeated alternately between
executing and stopping each time the timer’s set time is up.
MFUNC KEY
• When the M.FUNC key on the operation panel is pressed, the action is executed.
• In combination with the level action, the action is repeated alternately between
executing and stopping each time the M.FUNC key is pressed.
MATCH TIME
Match time setting allows you to preset a time to start/stop event/action functions.
Set the Action you want to happen in the Action setting space.
Match Times Setting
• There are three types of applicable Match Times. Select any of them in the Match
time dialog box on the right of the event/action setting screen.
Select the day and time you want the Match Time event to occur. If the day is set to
0, events will occur every day at the set time.
• In combination with the level action, the corresponding action is repeated
alternately between executing and stopping for each set time.
Selecting Edge or Level Action
Edge action (EDGE)
This action is executed when an event is detected.
Level action (LEVL)
This action is executed when an event is detected. When an event is released, this
action will be canceled.
• An edge action and a level action cannot be set at the same time.
• For a level action, only one setting can be made.
4.14 Event/Action, Match Time, and Group Settings
