FLOPPY
• LD_TRG1-3: Reads setup data from the floppydisk.
SCSI0 to SCSI7 (for DC100 with /C5 option only)
• LD_TRG1 to 3: Read set-up data from the SCSI device (MO, ZIP or PD).
SCSI0 to SCSI7 represent the SCSI ID numbers. Check the ID numbers of SCSI
devices that are connected, because ID numbers are displayed even if there are no
devices connected to them.
REPORT (available if the instrument is equipped with the REPORT function.)
• START (Edge action):
Starts making up a report.
• STOP (Edge action):
Stops making up a report.
(No Start/Stop for Level action)
Basic Setup for hourly, daily, or monthly report function must be ON.
• REPORT (Level action):
Starts/stops making up a report.
Note
If, in the SETUP mode, the report function is set to OFF for all data items, you cannot select the
action item REPORT.
Groups Setting
Make Group settings for DR group trend recording or for group computation statistics, in
the setting screen on the right side of the Event/Action setting screen.
4.14 Event/Action, Match Time, and Group Settings
