4.13 Setting Constants
Up to 60 constants (K01 to K60) can be set. (Thirty constants (K01 to K30) for the stand-
alone type.)
The number of significant digits is 5 excluding the decimal point. If an exponent is used,
the mantissa and exponent must consist of 5 digits and 2 digits, respectively.
• Configurable ranges:
–1.0000E+35 to –1.0000E-35
0
1.0000E-35 to –1.0000E+35
1
Click the Constant tab, or select Settings > SET (Regular) Settings > Constants
from the menubar
Constants tab
2
Set the Constants in the above Constants setting screen.
