Remote Monitor Software
Except for the below points, operation is equal to Logger software (see Section 5.4,
“Displaying Waveforms on the Monitor,” or Section 5.6, “Changing Monitor Display”).
• Using cursors for Alarm Log display.
If data renewal for waveform display is being paused (see Section 9.4), it is possible
to assign cursors on the Alarm Log screen of the Alarm Monitor, as shown in below
illustration.
Click the first data for cursor A, and drag it to the desired point for cursor B. The
cursors will also appear in the Color Graph and Trend monitors, if they are linked.
Cursor operation
Cursor operation is equal to Logger software (see Section 5.7, “Cursor Measurement”).
9.3 Group Settings/Displaying and Changing the Monitor/Using Cursors
