System Initialization
To initialize the settings of the connected device, do as follows:
1 Click the Diagnostic tab to display the Diagnostic setting screen.
2 To start initialization click the Initialization button (see below), or select Diagnostic
> Initialize from the menubar.
Initialization button
Note
Inputs, Measurement range, etc, will be set to the default values of the currently installed input
modules.
Display Errors
When Sub-Units don’t Appear on the Display
• Verify that the power of the sub-unit is turned ON.
• Verify that the extension cables are properly connected.
• Verify that the unit number of the sub-unit conforms the setting of the rotary switch.
• Verify that after initializing the system no other sub-units have been connected.
When Modules don’t Appear Correctly on Display
• Verify that the configuration of the modules is correct.
• Verify that after initializing the system no other modules have been wired.
When Any of the Following Errors Occur (red background)
The error(s) XX-YY will be displayed. The error YY means the following.
Error
No. Cause
C0 An input unit which does not match the system configuration has been connected.*1
C1 The module configuration has been altered after initializing the system
81 The number of connected modules exceeds the allowable number
82 Erroneous calibration has been carried out
83 Servicing is required*2
*1 Verify that the style number (for hardware) and release number (for software) match the
following rules:
• module’s style number ≤ main unit’s/sub-unit’s style number.
• main unit’s/sub-unit’s style number ≤ software’s release number.
*2 Contact your nearest sales representative.
3.5 System Reconstruction/Scan/Initialization
