Teledyne LeCroy Sierra Trainer Generation Commands
442 Sierra M6‐2 SAS/SATA Protocol Analyzer User Manual
WF_REC_RESOURCES_OUTPUT_E Advanced Wait Condition E
This command causes generation to
wait for Event "E" to occur that you
defined in the Generation Options
dialog described at the end of this
chapter.
WF_REC_RESOURCES_OUTPUT_F
wf_trainer_interconnect_signal_1
wf_trainer_interconnect_signal_2
wf_trainer_interconnect_signal_3
wf_trainer_interconnect_signal_4
Advanced Wait Condition F
This command causes generation to
wait for Event "F" to occur that you
defined in the Generation Options
dialog described at the end of this
chapter.
Events used to signal from one port to
another.
Events used to signal from one port to
another.
Events used to signal from one port to
another.
Events used to signal from one port to
another.
WF_COMRESET_COMINIT
COMRESET OOB Signals
WF_COMSAS COMSAS OOB Signals
WF_COMWAKE COMWAKE OOB Signals
WF_BLOCK1_MISC_RESERVED_0 reserved
WF_BLOCK1_MISC_RESERVED_1 reserved
WF_BLOCK1_MISC_RESERVED_2 reserved
WF_BLOCK1_MISC_RESERVED_3 reserved
WF_BLOCK1_MISC_RESERVED_4 reserved
WF_SATA_CONT primitive
WF_SATA_DMAT primitive
WF_SATA_EOF primitive
WF_SATA_ERROR primitive
WF_SATA_HOLD primitive
WF_SATA_HOLDA primitive
WF_SATA_PMACK primitive
WF_SATA_PMNAK primitive
WF_SATA_PMREQ_P primitive
Wait Command Name Description
