Sierra M6‐2 SAS/SATA Protocol Analyzer User Manual 435
Sierra Trainer Generation Commands Teledyne LeCroy
5.14.2 SATA Commands
Look at STP sample file for syntax.
 SEND_SATA_FRAME
 SendSATAFrame
 SATAData
 SATA_Data
 SATACRC
 SATA_CRC
 SATAXXXX
 SATA_XXXX
5.14.3 Primitive Commands
The following is a list of SAS and SATA primitives declared in Primitives.Decl.inc as Symbol
Chains. If you want to use these primitives in your script, you must also include
Primitives.Decl.inc in your script.
 SOF
 EOF
 SOAF
 EOAF
 ALIGN (0)
 ALIGN (1)
 ALIGN (2)
 ALIGN (3)
 NOTIFY (ENABLE SPINUP)
 NOTIFY (RESERVED 0)
 NOTIFY (RESERVED 1)
 NOTIFY (RESERVED 2)
 ACK
 NAK (CRC ERROR)
set_trainer_interconnect_signal_1
or settrainerinterconnectsignal_1
set_trainer_interconnect_signal_2
or settrainerinterconnectsignal_2
set_trainer_interconnect_signal_3
or settrainerinterconnectsignal_3
set_trainer_interconnect_signal_4
or settrainerinterconnectsignal_4
Set these signals to allow other ports to
wait on them using
WF_TRAINER_INTERCONNECT_SIGNAL_1
Set these signals to allow other ports to
wait on them using
WF_TRAINER_INTERCONNECT_SIGNAL_2
Set these signals to allow other ports to
wait on them using
WF_TRAINER_INTERCONNECT_SIGNAL_3
Set these signals to allow other ports to
wait on them using
WF_TRAINER_INTERCONNECT_SIGNAL_4
