Teledyne LeCroy Compliance Test (SATA)
332 Sierra M6‐2 SAS/SATA Protocol Analyzer User Manual
Figure 3.157: Power Source Control Dialog
3.27 Compliance Test (SATA)
The Compliance Test consists of a set of selectable tests to verify compliance with the
SATA specification. SATA compliance is at UTD Rev 1.4.
Note: The tests follow the Teledyne LeCroy MOI, which is described in the 
SATA_Digital‐Device_MOI_LeCroy_1.00_UTD1.4.pdf file in the installed Documents directory.
Note: You can start tests using the command line. The SAS/SATA Protocol Suite API Reference Manual,
Section 2.12, starting on page 153, explains how to write VB scripts to automate compliance
tests and generate results as RTF files.
To run a Compliance Test:
1. Click Analysis on the main toolbar and choose Compliance Test to open the
Compliance Test dialog (see Figure 3.108 on page 289 ).
