278 Sierra M6‐2 SAS/SATA Protocol Analyzer User Manual
Bus Condition
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
captured Bus Conditions in the Trace Viewer.
Incomplete Frames
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
Incomplete Frames in the Sample Viewer.
FIS
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
captured FIS items in the Sample Viewer.
ATA Command
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
captured ATA commands in the Sample Viewer.
Protocol Error
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
captured packets with the specified Protocol Errors in the Sample Viewer.
Port
When selected, depending on the Filter Type, the Show/Hide selection shows or hides
packet traffic for the selected port.
ATAPI SCSI Command
When selected, depending on the Filter Type, the Show/Hide selection shows or hides
ATAPI SCSI commands.
Miscellaneous
When you choose Miscellaneous, an additional dialog displays, allowing you to specify
the filtering of State Range and/or External Signal In (see
“Filter Miscellaneous” on
page 276 ).
3.8.6 Enable Filter
Select Filtering > Enable Filtering or click the Filter Enable button on the display
menu bar to toggle between Filtered and Unfiltered display.
3.8.7 Filter Idle
Depending on the Filter Type (Hide/Show), Idle packets in the Trace Viewer are shown or
hidden.
