Teledyne LeCroy Opening a Traffic Generation File
406 Sierra M6‐2 SAS/SATA Protocol Analyzer User Manual
1. In the Sierra Trainer window, select File > Convert > Convert .stg to .ssg to display
an Open dialog.
2. Use Files of Type SATrainer Generator Files (.stg).
3. Select an SATrainer Generator *.stg file.
4. Click Open. The application creates a Sierra Trainer Traffic Generator file (*.ssg).
Note:
SATrainer Generator Files (.stg) are for the CATC Tracer Exerciser model 10K.
5.6 Opening a Traffic Generation File
After the Traffic Generator file (*.ssg) file has been created, you can open it in the
application.
To open a Traffic Generator file:
1. Select File > Open on the Menu Bar, or click on the Toolbar, to display an Open
dialog.
2. Select a Generator text file (*.ssg) and click Open to display the file. (The install
directory contains example files.)
Figure 5.11: Sierra Trainer Generator File
