ATA Command Pattern

Double‐click ATA Command to open the ATA Command Pattern selection dialog.

Figure 2.63: SATA: ATA Command Pattern Dialog

Choose an ATA command from the drop‐down list and click OK.

Soft Reset (SATA only)

Double‐click Soft Reset to open the Soft Reset dialog.

Figure 2.64: SATA: Soft Reset Dialog

SAS vs. SATA: Not available in SAS.
