5. Modbus RTU
79
Modbus
5.3.8 Present Alarm Code Reading <>
(1) Function
This query reads the code indicating the normal status or alarm status of the controller.
In the normal status, 00
H
is stored.
[For details on alarm codes, refer to the operation manual for each controller.]
(2) Query format
Field Number of data items
(number of bytes)
RTU mode
8-bits data
Remarks
Start None Silent interval
Slave address [H] 1 Arbitrary Axis number + 1 (01
H
to 10
H
)
Function code [H] 1 03 Register reading
Start address [H] 2 9002 Present alarm code
Number of registers [H] 2 0001 Reading address 9002
H
Error check [H] 2 CRC (16 bits)
End None Silent interval
Total number of bytes 8
(3) Response format
A response message contains 16 bits of data per register.
Field Number of data items
(number of bytes)
RTU mode
8-bits data
Remarks
Start None Silent interval
Slave address [H] 1 Arbitrary Axis number + 1 (01
H
to 10
H
)
Function code [H] 1 03 Register reading
Number of data bytes [H] 1 02 Reading 1 register = 2 bytes
Data 1 [H] 2 Alarm code Alarm code [Hex]
Error check [H] 2 CRC (16 bits)
End None Silent interval
Total number of bytes 7
