4. Communicationn
40
Modbus
ᴾ
(9) Data of total moving distance (Address = 8402
H
) (ODOM)
Bit Symbol Name Function
31
-
Total moving distance
2147202832
30
-
Total moving distance
1073601416
29
-
Total moving distance
536800708
28
-
Total moving distance
268400354
27
-
Total moving distance
134200177
26
-
Total moving distance
67108864
25
-
Total moving distance
33554432
24
-
Total moving distance
16777216
23
-
Total moving distance
8388608
22
-
Total moving distance
4194304
21
-
Total moving distance
2097152
20
-
Total moving distance
1048576
19
-
Total moving distance
524288
18
-
Total moving distance
262144
17
-
Total moving distance
131072
16
-
Total moving distance
65536
15
-
Total moving distance
32768
14
-
Total moving distance
16384
13 - Total moving distance 8192
12 - Total moving distance 4096
11 - Total moving distance 2048
10 - Total moving distance 1024
9 - Total moving distance 512
8 - Total moving distance 256
7 - Total moving distance 128
6 - Total moving distance 64
5 - Total moving distance 32
4 - Total moving distance 16
3 - Total moving distance 8
2 - Total moving distance 4
1 - Total moving distance 2
0 - Total moving distance 1
It shows the total moving distance.
Total moving distance are read out in binary codes.
* Corresponding Model: PCON-CA/CFA, SCON-CA,
ERC3
