5.6.2 Writing Position Table Data
(1) Function
Position table data can be changed using this query.
Every time an access is made to the start address list (address +0000
H
to +000E
H
), it is read out
of the non-volatile memory in the unit of 1 position data, and gets stored to the non-volatile
memory after the writing is executed.
* The EEPROM has a rewrite life of approx. 100, 000 times due to device limitations. If the
position table data is written frequently, the EEPROM will reach its rewrite life quickly and a
failure may occur. Accordingly, be careful not to let unexpected loops, etc., occur due to the
logics on the host side.
(2) Start address list
In a query input, each address is calculated using the formula below:
1000
H
+ (16 x Position number)
H
+ Address (Offset)
H
Example Change the speed command register for position No. 200
1000
H
+ (16 x 200 = 3200)
H
+ 4
H
= 1000
H
+ C80
H
+ 4
H
= 1C84
H
“1C84” becomes the input value for the start address field of this query.
* The maximum position number varies depending on the controller model and the PIO pattern
currently specified.
„ Position data change resisters
Address Symbol Name Sign
Register
size
Byte
size
Input
unit
+0000 PCMD Target position { 2 4 0.01 mm
+0002 INP Positioning band 2 4 0.01 mm
+0004 VCMD Speed command 2 4 0.01 mm/sec
+0006 ZNMP Individual zone boundary + { 2 4 0.01 mm
+0008 ZNLP Individual zone boundary - { 2 4 0.01 mm
+000A ACMD Acceleration command 1 2 0.01 G
+000B DCMD Deceleration command 1 2 0.01 G
+000C PPOW Push-current limiting value 1 2 %
+000D LPOW Load current threshold 1 2 %
+000E CTLF Control flag specification 1 2
* Addresses starting with “+” indicate offsets.
