6. Modbus
ASCII
187
Modbus
6.4. Data and Status Reading (queries Using Code 03)
6.4.1 Reading Consecutive Multiple Registers
(1) Function
These registers read the contents of registers in a slave.
This function is not supported in broadcast communication.
(2) Start address list
With RC Series controllers, the sizes of send/receive buffers are set to 256 bytes, respectively.
Accordingly, a maximum of 123 registers worth of data consisting of 247 bytes (one register uses
two bytes), which is 9 bytes (header + slave address + function code + error check + trailer) of 256
bytes, can be queried in the ASCII mode. In other words, all of the data listed below (total 21
registers) can be queried in a single communication. It is also available to refer to multiple registers
of the addresses in a row at one time of sending and receiving.
Address [H] Symbol Name Sign Register size Byte
0500 ALA0 Alarm detail code 1 2
0501 ALA0 Alarm address 1 2
0502 - Always 0 - - 2
0503 ALC0 Alarm code 1 2
0504,0505 ALT0 Alarm occurrence time 2 4
8400,8401 TLMC Total moving count (Note1) 2 4
8402,8403 ODOM Total moving distance (Note1) 2 4
841A,841B TIMN Present time(dedicated for SCON-CA) 2 4
8420,8421 TIMN
Present time
(dedicated for PCON-CA/CFA)
2 4
842E,842F TFAN Total fan driving time
(dedicated for PCON-CFA)
2 4
9000, 9001 PNOW Current position monitor { 2 4
9002 ALMC Present alarm code query 1 2
9003 DIPM Input port query 1 2
9004 DOPM Output port monitor query 1 2
9005 DSS1 Device status query 1 1 2
9006 DSS2 Device status query 2 1 2
9007 DSSE Expansion device status query 1 2
9008, 9009 STAT System status query 2 4
900A, 900B VNOW Current speed monitor { 2 4
900C, 900D CNOW Current ampere monitor { 2 4
900E, 900F DEVI Deviation monitor { 2 4
9010, 9011 STIM System timer query 2 4
9012 SIPM Special input port query 1 2
9013 ZONS Zone status query 1 2
9014 POSS Position complete number status query 1 2
9015 SSSE Expansion system status register 1 2
901E FBFC Force feedback data monitor { 2 4
Note 1 Dedicated for PCON-CA/CFA, SCON-CA and ERC3
*) Please refer to
“ 6.2 ASCII Code Table.”
