7. T
roubleshooting
309
Modbus
*1 Connect a PC to the host following the procedure explained in sections 3.1, 3.2 and 3.3.
[1] Start the PC software.
[2] Select [Application Setting] from the [Setting] menu.
Check that the port is set to the port number of the PC used and that the last axis number is set to a
value larger than the number of connected axes in the Communication Setting window.
(If any settings are wrong, correct the settings and then restart the PC for RC.)
Fig. 9.2
Select [Application Setting]
from the [Setting] menu.
Check that the port is set to
the port number of the PC
used (pay special attention if
an USB port is used).
Check that the last axis
number is set to a value larger
than the number of connected
axes
Fig.9.1
