Appendix
Battery Backup Function
350
Appendix
The absolute encoder backup specifications are shown in the table below.
List of Absolute Encoder Backup Functions
Battery type AB-5 (by IAI)
Battery voltage 3.6 V
Current capacity 2000 mAH
Detection voltage for battery
voltage low alarm
(Typical) 3.1 V 3.0 V a 3.2 V
Detection voltage for battery
voltage low error
(Typical) 2.5 V 2.3 V ~ 2.7 V
Time after alarm detection until
error detection (reference)
10 days at 20qC based on continuous operation; 7 days if the power is not
supplied.
10 days at 40qC based on continuous operation; 2.5 days if the power is not
supplied.
Minimum data retention voltage Min. 2.7 V (Varies depending on the encoder characteristics.)
Time after error detection until
data loss (reference)
With an absolute encoder, an absolute reset must be performed once an
error is detected.
Data protection time during
battery replacement
15 minutes (Maximum retention time when
no battery is installed in the battery holder)
Data is retained by the super
capacitor inside the controller.
Temperature 40qC, power supplied 0% of
the time
2 years
Guide on when to replace
battery Temperature 40qC, power supplied 50%
of the time
4 years
