Part 2 Programs
Chapter 9 Example of Building a System
265
Part 2 Programs
3. Overview of the Screw-Tightening System
This system consists of axis-1 and axis-2 actuators, Z-axis cylinder, screw-tightening device and parts
feeder, and tightens the screws fed by the parts feeder at the specified positions on the load.
Axis 1
Axis 2
Parts feeder
Z-axis cylinder
Screw-tightening device
Load
Operation box
