Moving back and forth between two points – IAI America ASEL User Manual
Page 295
Part 2 Programs
Chapter 10 Example of Building a System
273
Part 2 Programs
5. Moving Back and Forth between Two Points
Description
Moves back and forth between two points.
Flowchart
x
The actuator moves back and forth between P1 and P2 indefinitely.
x
Use of only 1 axis is assumed.
x
Enter TAG in the first of the steps to be repeated, and enter GOTO
in the last of the steps to be repeated.
Application program
Position data
Start
Homing
Move to P1
Move to P2
