1. By Function
Variables can be specified indirectly in the operand 1, operand 2 and output fields.
Symbols can be input in the condition, operand 1, operand 2 and output fields.
The input items in ( ) under operand 1 and operand 2 are optional.
Once an “actuator control declaration” command is executed in a program, the command will remain valid as
long as the program is running. To change the values (in operand 1, operand 2, etc.) already set by the
“actuator control declaration” command, the necessary parts of the program must be set again. In other words,
the values set by the last executed command will prevail.
The output field will be turned OFF when the command is executed. Once the execution is completed, the
output field may be turned ON depending on the operation type condition in the output field. (The output field
will remain OFF if the condition is not satisfied.)
Note: The output field of a comparison command CP†† (CPEQ, CPNE, CPGT, CPGE, CPLT and CPLE) will
not be turned OFF when the command is executed.
Operation type in the output field
CC: Command was executed successfully,
ZR: Operation result is zero, PE: Operation is complete,
CP: Command part has passed, TU: Time up
EQ: Operand 1 = Operand 2, NE: Operand 1 z Operand 2,
GT: Operand 1 > Operand 2, GE: Operand 1 t Operand 2,
LT: Operand 1 < Operand 2, LE: Operand 1 d Operand 2
Category Condition Command Operand 1 Operand 2 Output Function Page
Optional LET Assignment variable Assigned value ZR Assign 95
Optional TRAN
Copy-destination
variable
Copy-source variable ZR Copy 96
Variable
assignment
Optional CLR Start-of-clear variable End-of-clear variable ZR Clear variable 97
Optional ADD Augend variable Addend ZR Add 98
Optional SUB Minuend variable Subtrahend ZR Subtract 98
Optional MULT Multiplicand variable Multiplier ZR Multiply 99
Optional DIV Dividend variable Divisor ZR Divide 99
Arithmetic
operation
Optional MOD
Remainder
assignment variable
Divisor ZR Calculate remainder 100
Optional SIN
Sine assignment
variable
Operand [radian] ZR Sine 101
Optional COS
Cosine assignment
variable
Operand [radian] ZR Cosine 101
Optional TAN
Tangent assignment
variable
Operand [radian] ZR Tangent 102
Optional ATN
Inverse-tangent
assignment operation Operand
ZR Inverse tangent 102
Function
operation
Optional SQR
Root assignment
variable
Operand ZR Root 103
Optional AND
AND operand
variable
Operand ZR Logical AND 104
Optional OR OR operand variable Operand ZR Logical OR 105
Logical
operation
Optional EOR
Exclusive-OR
operand variable
Operand ZR Logical exclusive-OR 106
Comparison Optional CP†† Comparison variable Comparison value
EQ, NE, GT,
GE, LT, LE
Compare 107
Optional TIMW Wait time (sec) Prohibited TU Wait 108
Optional TIMC Program number Prohibited CP Cancel waiting 109
Timer
Optional GTTM
Time assignment
variable
Prohibited CP Get time 110
Optional BT†† Start output, flag (End output, flag) CP Output, flag [ON, OF, NT] 111
Optional BTPN Output port, flag Timer setting CP Output ON pulse 112
Optional BTPF Output port, flag Timer setting CP Output OFF pulse 113
Optional WT†† I/O, flag (Wait time) TU Wait for I/O, flag [ON, OF] 114
Optional IN Head I/O, flag End I/O, flag CC Input binary (32 bits max.) 115
Optional INB Head I/O, flag Conversion digits CC Input BCD (8 digits max.) 116
Optional OUT Head output, flag End I/O, flag CC Output binary (32 bits max.) 117
Optional OUTB Head output, flag Conversion digits CC Output BCD (8 digits max.) 118
I/O, flag
operation
Optional FMIO Format type Prohibited CP
Set IN (B)/OUT (B)
command format
119
