3 - 6
P1/1
C X - 1 2 0 0
STATUS
Scaled Fb
RPM
Setpoint X
State
FI1 RPM
Ld Posn
FI2 RPM
Fb Posn 0
F-STOP
0.0
0.0
0.0
0.0
The large
number
display.
This bar
displays the
name of the
screen.
The E.U. of the
value in the
large number
display.
To display the
code select line,
press the Code
key. To display a
parameter and its
value, enter a
parameter code
and press the
Enter key. You can
select and change
any control
parameter from
here.
The value of
this parameter
is displayed in
the large
number
display.
This bar
displays error
and status
m e s s a g e s .
The status
lines display
the current
value or status
of the
parameter .
Also indicates
the number of
characters
allowed. You
can change a
Control
Parameter
when the line is
active.
This bar
displays the
current page &
total pages.
"Alm" will blink
in this bar if
there is an
active alarm
status.
Press the Par
keys to scroll
the cursor up
or down and
make the line
active.
Press the Help
key to go to the
active line's help
screen.
Status Screen
Press the Status key to access the Status screen. The Status screen has a large number display for a quick, visual
reference to a frequently used parameter, as well as its value and E.U. (Scaled Feedback is the default parameter).
Below the large number display, the Status screen lists six frequently used parameters. In addition to the frequently
used parameters, the line at the bottom of the display, called the code select line, allows you to access and display
any parameter and change any Control Parameter's value. The Status screen can be customized to reflect the
parameters that you access most frequently. To customize the Status screen refer to System Setup- Control
Parameters: Device Configure/Status Screen Setup.
