7 - 44
FUNCTION (07) DATA WRITE PLC PROGRAM
Table 51 Host Transmission
Byte #
DESC
Decimal
1 2 3 4 5-132 133 134 135
STX Length Address Function PLC Program ETX CRC
Hex
2 9-135 0-99 7 0-255 3 0-65535
02 09-87 00-63 07 00-FF 03 0000-FFFF
PLC Program Field - (2 to 128 Bytes)
This field should contain a PLC Program, which may be any where from 2 to 128 bytes of data. The format
for this data should be in pairs of Commands & Operands:
PLC Command - 1 byte
PLC Operand
- 1 byte
Refer to Appendices: Appendix K for the PLC Program Commands and Appendices: Appendix L for the PLC
Program Operands.
Message Length = 9 to 135 bytes
Table 52 CX-1200 Response
Byte #
DESC
Decimal
1 2 3 4 5 6 7 8
STX Length Address Msg Error Error Code ETX CRC
Hex
2 8 1-99 0-255 0-32 3 0-65535
02 08 01-63 00-FF 00-20 03 0000-FFFF
Message Length = 8 bytes
