Table 7-7 CX-1200 Response
Character #
1
2
3
4
5
6-22
23
24
25
26
27
DESC
ASCII
STX
Address
Msg Error
Data Field ETX
CRC (0000 - FFFF)
^B
0-9
1-9
0-F
0-F
^C
0-F
0-F
0-F
0-F
Data Field per Table 7-7
Number of Parameters x 17 characters/parameter (14 parameters max. = 238 characters)
Character #
DESC
ASCII
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Parm Number Error Code Res Fmt
Parameter Value (0000000000-9999999999
0-9 0-9 0-9 0-3 0-9 0-9
0-2 0-9 0-9 0-9 0-9 0-9 0-9 0-9 0-9 0-9 0-9
Parameter Number
- 3 characters.
Parameter Error Code
- 2 characters.
Resolution
- 1 character.
Format
- 1 character.
Parameter Value
- 10 characters.
Message Length = 27 to 248 characters.
