J - 1
PLC Command Equivalent Logic Ladder
APPENDIX J: PLC DEFAULT PROGRAM
LOGIC
LOAD 8 DI_8
OUT 140 Blk Sel A
DI- 8
8
BlkSel A
140
LOAD 9 DI_9
OUT 135 Cntr 1 Rst
DI- 9
9
Cntr 1 Rst
135
LOAD 10 DI_10
OUT 174 Re-Learn
DI-10
10
Re-Learn
174
LOAD 12 DI_12
OUT 152 RstFI1Psn
OUT 153 RstFI2Psn
DI-11
11
OpnLpRqst
187
LOAD 14 DI_14
OUT 169 Scroll Dn
DI-12
12
RstFI1Psn
152
LOAD 13 DI_13
OUT 172 LdSyncOff
OUT 173 FbSyncOff
DI-14
14
Scroll Dn
169
LOAD 15 DI_15
OUT 168 Scroll Up
DI-13
13
LdSyncOff
172
DI-15
15
Scroll Up
168
LOAD 11 DI_11
OUT 187 OpnLpRqst
FbSyncOff
173
RstFI2Psn
153
LOAD 69 FbSyncRcv
OUT 130 Cntr 1 Inc
FbSyncRcv
69
Cntr 1 Inc
130
(Continued)
