C - 17
(Continued)
Appendix C: Parameter Summary Numeric Quick Reference (continued)
MP-115 PLC 55-48
PLC 55-48 (MP-115) displays the status of the internal PLC status bits 55-48 (See graphic below). A “1” in any bit
indicates that the bit is “active”.
Not In Use
MaxFI1Hz
CO Sign
Drive Enable
Ramp Active
RR@0Spd
Fb@0Spd
MaxFbSpd
Bit Name Description
Not In Use
MaxFI1Hz
CO Sign
Control Output sign is negative (-)
DrvEn Drive Enable
RmpActive Ramp Active
RR@0Spd RampedRef (MP-31) less than Zero Speed (CP-332)
Fb@0Spd Feedback is less than Zero Speed (CP-332)
MaxFbSpd Feedback at Max Fb (CP-329)
Minimum Value: 00000000 Maximum Value: 11111111
Units: Coded
