FUNCTION (10) DATA READ PARAMETER CONSTANT TABLE
Table 7-16 Host Transmission
Character # 1 2 3 4 5 6-8 9 10 11 12 13
DESC
ASCII
STX Address Function Data Field ETX CRC (0000 - FFFF)
^B 0-9 1-9 1 0 ^C 0-F 0-F 0-F 0-F
Data Field per Table 7-16
Number of Parameters x 3 characters/parameter (4 parameters max. = 12 characters)
Character #
DESC
ASCII
6 7 8
0-9 0-9 0-9
Parameter Number 100's Parameter Number 10's Parameter Number 1's
Parameter Number - 3 characters.
Message Length = 13 to 22 characters.
Table 7-17 CX-1200 Response
Character # 1 2 3 4 5 6-241 242 243 244 245 246
DESC
ASCII
STX Address Msg Error Data Field ETX CRC (0000 - FFFF)
^B 0-9 1-9 0-F 0-F ^C 0-F 0-F 0-F 0-F
Data Field - Number of Parameters x 59 characters/parameter (4 parameters max. = 236 characters).
Parameter Number
- 3 characters (000 - 999).
Parameter Error Code - 2 characters (00 - 32).
Title Text String - 15 characters (String of 15 printable ASCII characters).
Minimum Value Format* - 1 character (0 - 2).
Minimum Value* - 10 characters (0000000000 - 9999999999).
Maximum Value Format* - 1 character (0 - 2).
Maximum Value* - 10 characters (0000000000 - 9999999999).
Default Value Format* - 1 character (0 - 2).
Default Value* - 10 characters (0000000000 - 9999999999).
Minimum Resolution* - 1 character (0 - 9) Resolution for Minimum Value.
Maximum Resolution* - 1 character (0 - 9) Maximum Resolution for any value.
Default Resolution* - 1 character (0 - 9) Resolution for Default Value.
Parameter Control byte - 2 characters (ASCII HEX Number, 00 - FF).
Field Length - 1 character (0 - 9) Length of parameter field.
* These fields will be filled with zeros for all Monitor Parameter requests.
Message Length = 69 to 246 characters
