Appendix C: Parameter Summary Numeric Quick Reference (continued)
MP-133 PLC 203-196
PLC 203-196 (MP-133) displays the status of the internal PLC control bits 203-196 (See graphic below). A “1” in any bit
indicates that the bit is “active”.
Not In Use
Not In Use
Not In Use
Not In Use
OpenLoop
VelLoop
PosnLoop
LgErrLoop
Minimum Value: 00000000 Maximum Value: 11111111
Units: Coded
MP-134 PLC 211-204
PLC 211-204 (MP-134) displays the status of the internal PLC control bits 211-204. (See graphic below). A “1” in any bit
indicates that the bit is “active”.
Not In Use
Not In Use
Not In Use
Not in Use
Not In Use
Not In Use
Not In Use
Not In Use
Minimum Value: 00000000 Maximum Value: 11111111
Units: Coded
