CONTREX CX-1200 User Manual

Page 461

G - 2

MP#

MP Name

Screen

................................. System Monitor\Run Monitor\pg 3

................................. System Monitor\Std Signals Monitor\pg 2

................................. Device Tests\Std Signals Tests\pg 1

MP-10

Ld Posn ................... Status\pg 1

................................. Scaling\Lead\pg 1

................................. Scaling\Offsets & Phase\pg2

................................. Tuning\Large Error\pg 1

................................. Alarms & Limits\Limits\pg 2

................................. System Monitor\Run Monitor\pg 1

................................. System Monitor\Run Monitor\pg 2

................................. System Monitor\Position\pg 1

................................. System Monitor\Std Signals Monitor\pg 1

MP-11

LdJobSize ................ System Monitor\Job Sizes\pg 1

MP-12

LdJbSzVar ............... System Monitor\Job Sizes\pg 1

MP-13

LdJbSzAvg .............. System Monitor\Run Monitor\pg 2

................................. System Monitor\Job Sizes\pg 1

MP-14

LdJbSzAct ............... Scaling\Job Sizes\pg1

MP-15

LdNetOfst ............... Scaling\Offsets & Phase\pg1

................................. Scaling\Offsets & Phase\pg2

................................. System Monitor\Position\pg 1

MP-20

Fb Posn ................... Status\pg 1

................................. Scaling\Follower\pg 1

................................. Scaling\Offsets & Phase\pg2

................................. Tuning\Large Error\pg 1

................................. Alarms & Limits\Limits\pg 2

................................. System Monitor\Run Monitor\pg 1

................................. System Monitor\Run Monitor\pg 3

................................. System Monitor\Position\pg 1

................................. System Monitor\Std Signals Monitor\pg 2

MP-21

FbJobSize ................ System Monitor\Job Sizes\pg 1

MP-22

FbJbSzVar ............... System Monitor\Job Sizes\pg 1

MP-23

FbJbSzAvg ............... System Monitor\Job Sizes\pg 1

Appendix G: Monitor Parameter Screen Locator (continued)

(Continued)
