Appendix L: PLC Program Operands (continued)
(Continued)
Op Name
Related CP
60
Cmpr1 Out, Numerical Comparator 1 result ............................. CP-380,386,392
61
Cmpr2 Out, Numerical Comparator 2 result ............................. CP-381,387,393
62
Cmpr3 Out, Numerical Comparator 3 result ............................. CP-382,388,394
63
Cmpr4 Out, Numerical Comparator 4 result ............................. CP-383,389,395
64
Reserved
65
OutOfPosn, Out of Position
66
LdSyncNPr, Lead Sync pulse Not Present
67
FbSyncNPr, Follower Sync pulse Not Present
68
LdSyncRcv, Lead Sync pulse Received
69
FbSyncRcv, Follower Sync pulse Received
70
OneSecSqW, One Second Square Wave Output
71
Reserved
72
F-Stop, F-Stop State (Monitor Only) ......................................... MP-50
73
R-Stop, R-Stop State (Monitor Only) ........................................ MP-50
74
H-Stop, H-Stop State (Monitor Only) ....................................... MP-50
75
Run, Run State (Monitor Only) ................................................. MP-50
76
Jog Fwd, Jog Forward State (Monitor Only) ............................ MP-50
77
Jog Rvs, Jog Reverse State (Monitor Only) ............................. MP-50
78
Reserved
79
DiagState, Diagnostics State (Monitor Only) ............................ MP-50
80
Blk Sel 0, Block 0 Selected (Active) - (Monitor Only) ............. MP-51
81
Blk Sel 1, Block 1 Selected (Active) ........................................ MP-51
82
Blk Sel 2, Block 2 Selected (Active) ........................................ MP-51
83
Blk Sel 3, Block 3 Selected (Active) ........................................ MP-51
84
Blk Sel 4, Block 4 Selected (Active) ........................................ MP-51
85
Blk Sel 5, Block 5 Selected (Active) ........................................ MP-51
86
Blk Sel 6, Block 6 Selected (Active) ........................................ MP-51
87
Blk Sel 7, Block 7 Selected (Active) ........................................ MP-51
88
Reserved
89
RvsCmd, Reverse Direction Command indicated
