5 - 12
DEVICENET SETUP P1/2
The DeviceNet Setup screens include parameters to configure the DeviceNet option card for network
communications. Page 1 of the DeviceNet Setup screens includes the Serial Number attribute of the Identity
Object and the MAC ID and Baud Rate attributes from the DeviceNet Object. Page 2 is used to enter the
eight Parameter Codes for the Assembly Queue. Refer to "DeviceNet Card Technical Manual" for more
detailed information on DeviceNet operations.
DN MAC ID
DN MAC ID is the DeviceNet Media Access Control Identifier. The MAC ID is used to assign a unique identifier or
address to each node on the network. Assign a different MAC ID to each CX-1200 device on the network from 0 to 63.
DN Baud Rate
The DN Baud Rate is the network data or transfer rate. Enter the number from the listing below that corresponds to the
desired baud rate:
1 = 125k bps
2 = 250k bps
3 = 500k bps
Serial Number
Serial Number is the serial number from the DeviceNet card in this CX-1200 controller. If the card was factory installed,
the Serial Number should already be entered. If the card is being field installed, enter the Serial Number from the label
on the card or recorded in the DeviceNet Card Technical Manual.
